Infusion Pump ZNB-XD
Product Specifications
|
Parameter |
Specification |
|
Model |
Infusion Pump ZNB-XD |
|
Pumping Mechanism |
Curvilinear peristaltic |
|
IV Set |
Compatible with IV sets of any standard |
|
Flow Rate |
1-1200 ml/h (in 0.1 ml/h increments) |
|
Purge, Bolus |
Purge when pump stops, bolus when pump starts, rate at 500, 800, 1200 ml/h |
|
Accuracy |
±3% |
|
VTBI |
1-20000 ml (in 0.1 ml increments) |
|
Infusion Mode |
ml/h, drop/min, time-based, body weight, nutrition |
|
KVO Rate |
1-5 ml/h (in 0.1 ml/h increments) |
|
Alarms |
Occlusion, air-in-line, door open, end program, low battery, end battery, AC power off, motor malfunction, system malfunction, reminder alarm |
|
Additional Features |
Real-time infused volume, automatic power switching, mute key, purge, bolus, system memory, history log |
|
Occlusion Sensitivity |
High, medium, low |
|
History Log |
50000 events |
|
Air-in-line Detection |
Ultrasonic detector |
|
Wireless management |
Optional |
|
Drop Sensor |
Optional |
|
Vehicle Power (Ambulance) |
12±1.2 V |
|
Power Supply, AC |
110/230 V (optional), 50-60 Hz, 20 VA |
|
Battery |
9.6±1.6 V, rechargeable |
|
Battery Life |
5 hours at 25 ml/h |
|
Working Temperature |
10-30 ℃ |
|
Relative Humidity |
30-75% |
|
Atmospheric Pressure |
860-1060 hpa |
|
Size |
130145228 mm |
|
Weight |
2.5 kg |
|
Safety Classification |
Class Ⅰ, type CF |
